10A Current Metal Push Button Switch

As the core series of push-button switches developed by Yueqing Tongda for the industrial control and smart device sectors, this product is positioned around the core concept of 'multi-function integration, high reliability, and durability.' It combines the company's more than 30 years of manufacturing craftsmanship with patented transmission mechanism technology. Leveraging advantages such as illuminated indicators, dual-mode control, and wide load adaptability, it is widely used in industrial automation, smart home devices, medical equipment, automotive electronics, and many other fields.

Strengthened structural design and material selection have resulted in a mechanical lifespan of over 500,000 cycles and an electrical lifespan of 100,000 cycles, far exceeding the industry average, allowing stable operation in high-frequency daily industrial scenarios for over 8 years. The casing is made of flame-retardant PA66 reinforced nylon (UL94 V-0 rating), with an insulation resistance of ≥100MΩ (500V DC) and terminal voltage resistance of 2000V AC. The operating temperature range is from -40°C to 120°C. It has passed 72 hours of salt spray corrosion testing and 10-60Hz vibration testing. The basic version has an IP40 protection rating, while the upgraded version can reach IP67 for dust and water resistance, making it suitable for complex environments such as humid workshops, outdoor equipment, and medical cleanrooms.

The in-vehicle version is used for the function control of the central console in new energy vehicles, with no performance degradation after high and low temperature tests from -40℃ to 85℃, and it is certified according to the IATF16949 automotive industry standard. The outdoor equipment version features an IP67 protection design, suitable for operation buttons on agricultural machinery and outdoor charging piles, capable of resisting rain and dust, and operates stably in fieldwork and outdoor environments.
