Monitoring Switch for Frigidaire Microwave

Monitoring Switch for Frigidaire Microwave

Monitoring Switch for Frigidaire Microwave is offered by China manufacturers WEIPENG®. Our competitive pricing and popularity in the European and American markets make us an ideal long-term partner for your Household appliances ultra-small micro switch needs in China.

Model:HK-04G-LZ-108

Send Inquiry

Product Description


WEIPENG® is a leading China Monitoring Switch for Frigidaire Microwave manufacturers, suppliers and exporter.

Tongda Wire Electric Monitoring Switch for Frigidaire Microwave ntroduction


Micro switches are generally based on unassisted compression accessories, and derive small stroke type and large stroke type. According to the different compression accessories added, it can be divided into various forms such as button type, reed roller type, lever roller type, short boom type, long boom type, etc.


Tongda Wire Electric Monitoring Switch for Frigidaire Microwave Parameter (Specification)


Switch Technical Characteristics:
ITEM Technical Parameter Value
1 Electrical Rating 5(2)A 125V/250VAC 10(3)125V/250VAC
2 Contact Resistance ≤50mΩ  Initial value
3 Insulation Resistance ≥100MΩ  (500VDC)
4
Dielectric
Voltage
Between
non-connected terminals
500V/0.5mA/60S
Between terminals
and the metal frame
1500V/0.5mA/60S
5 Electrical Life ≥10000 cycles
6 Mechanical Life ≥100000 cycles
7 Operating Temperature -25~125℃
8 Operating Frequency Electrical :15 cycles
Mechanical :60 cycles
9 Vibration Proof Vibration Frequency :10~55HZ;
Amplitude :1.5mm;
Three directions :1H
10 Solder Ability :
More than 80% of immersed part
shall be covered with solder
Soldering Temperature : 235±5℃
Immersing Time :2~3S
11 Solder Heat Resistance Dip Soldering :260±5℃ 5±1S
Manual Soldering :300±5℃ 2~3S
12 Safety Approvals UL、CSA、VDE、ENEC、CE
13 Test Conditions Ambient Temperature :20±5℃
Relative Humidity :65±5%RH
Air Pressure : 86~106KPa


Tongda Micro Switch Monitoring Switch for Frigidaire Microwave Detail
