Square Rocker Switch Red
  • Square Rocker Switch RedSquare Rocker Switch Red

Square Rocker Switch Red

Square Rocker Switch Red is offered by China manufacturers WEIPENG®. Our competitive pricing and popularity in the European and American markets make us an ideal long-term partner for your Square rocker switch needs in China.

Model:GQ-141-1

Send Inquiry

Product Description

WEIPENG® is a professional leader China Square Rocker Switch manufacturers with high quality and reasonable price. Welcome to contact us.

Tongda Wire Electric Square Rocker Switch RedIntroduction


The Square rocker switch, also known as a toggle switch or rocker switch, is a type of electronic switch commonly used as a power switch for various electronic devices. It gets its name from its boat-shaped knob, which distinguishes it from other types of switches. The structure of the boat switch is similar to a toggle switch, with the main difference being the boat-shaped knob.
Boat switches come in different types, with contacts ranging from single pole single throw to double pole double throw, and some switches may have additional features such as indicators or illumination options. These switches are widely used in different industries for their reliability and durability.



Tongda Wire Electric Square Rocker Switch Red Test Conditions


Switch Technical Characteristics:
ITEM Technical Parameter Value
1 Electrical Rating 10(1.5)A/16(3)A/10(3)A 250VAC
2 Contact Resistance ≤50mΩ  Initial value
3 Insulation Resistance ≥100MΩ (500VDC)
4
Dielectric
Voltage
Between
non-connected terminals
1500V/0.5mA/60S
Between terminals
and the metal frame
3000V/0.5mA/60S
5 Electrical Life ≥10000 cycles
6 Mechanical Life ≥100000 cycles
7 Operating Temperature 0~125℃
8 Operating Frequency Electrical :15 cycles
Mechanical :60 cycles
9 Vibration Proof Vibration Frequency :10~55HZ;
Amplitude :1.5mm:
Three directions :1H
10 Solder Ability :
More than 80% of immersed part
shall be covered with solder
Soldering Temperature :235±5℃
Immersing Time :2~3S
11 Solder Heat Resistance Dip Soldering :260±5℃ 5±1S
Manual Soldering :300±5℃ 2~3S
12 Safety Approvals UL、CSA、VDE、ENEC、TUV、CE、CQC
13 Test Conditions Ambient Temperature :20±5℃
Relative Humidity :65±5%RH
Air Pressure : 86~106KPa

Tongda Wire Electric Square Rocker Switch Red Test Method


To test the durability of the switch, it is necessary to repeatedly open and close the switch until it is damaged. If this cannot be done manually, a small motor can be used to drive the eccentric opening and closing of the switch, while a counter is used to record the number of times it has been operated. The switch must have safety certification, such as CQC for domestic sales or UL, CUL, VDE, ENEC, TUV for sales in specific foreign countries.
