IP65 vs IP67 Waterproof Rocker Switch: Performance Test & Application Guide

When it comes to electrical components, longevity and dependability are key points of consideration when used in environments subject to water. Of the wide range of available options, a waterproof rocker switch is an outstanding candidate for numerous applications. In this article, the performance of IP65 and IP67 waterproof rocker switches are described along with an application guide to aid in selecting the appropriate switch type for your application.

Understanding Waterproof Ratings: IP65 vs IP67

To get a better understanding of Ingress Protection and how it can be applied, we need a general overview of what the ratings imply. The first two digits of the rating represent dust protection (first digit) and water or moisture protection (second digit).

In the case of an IP65 rating, it indicates that the switch has a high level of protection against the entry of dust (in other words, it is dust-tight), and is designed to withstand low-level water jets from any angle. A switch with an IP67 rating indicates that it has the same level of protection against the entry of dust and is also able to be submerged in water for up to 30 minutes at depths of up to 1 meter without being damaged. It is crucial to understand these differences in order to select the correct switch for your application.

Performance Comparison: IP65 vs IP67

In order to properly assess the performance of an IP65 and IP67 waterproof rocker switch, several different test methods were used to evaluate the switches in a controlled wet environment. The results found:

Water Resistance: Both switches have demonstrated their performance regarding resistance to water; however, the IP67 rated switch maintained a higher degree of functionality than the other tested switch at full immersion.

Dust Protection: The results suggest that both types of switches could work well in locations where there is a high probability of dust and/or dirt, as both passed all dust containment testing performed.

Electrical Safety: Test results confirm no short circuiting or malfunction of the switches within a wet environment and that both switches were tested to indicate they do not exceed the safe operating voltage levels.

Applications of Waterproof Rocker Switches

Your choice of whether to use an IP67 or an IP65 waterproof rocker switch will depend largely on your specific application. Below are some examples of common applications for each type of switch:

The IP65 waterproof rocker switch is ideal for:

In contrast, the IP67 waterproof rocker switch is better suited for:

How to Waterproof a Rocker Switch

You can increase the waterproofness of your standard rocker switch if you have one that requires moisture protection. Here’s how to do it:

1. Apply a silicone sealant around the edges of the switch.
2. Use heat-shrink tubing over electrical connections to prevent moisture ingress.
3. Choose a mounting option that minimizes exposure to water flow, such as offset mounting.

Although the above steps may be used as extra protection, ordering a factory-rated water resistant rocker switch may provide greater reliability.

FAQ

Do they make waterproof light switches?

Rocker-style waterproof light switches are available in many designs and have an IP65 or IP67 rating; they are suitable for inside and outside use.

What are the benefits of using a waterproof rocker switch?

Rocker switches which are waterproof deliver superior durability by allowing electrical parts to be protected in wet and humid environments while reducing maintenance costs and increasing service life.

Conclusion

When selecting an IP65 or IP67 rockerswitch keep in mind the specific environment of your project. IP65 is an excellent middle ground, able to provide good protection against dust as well as resistant to both water vapor/droplets (also known as "water jets") and the impact of raindrops; however, it does not have the same level of protection as IP67 when submerged in water. Regardless of one's choice depending on the specific requirements associated with your project, having quality weatherproofrockerswitches will provide dependable performance and reliability throughout even the harshest conditions.
