Rectangle Size Rocker Switch
  • Rectangle Size Rocker SwitchRectangle Size Rocker Switch

Rectangle Size Rocker Switch

WEIPENG® is a renowned manufacturer and supplier of Rectangle Size Rocker Switch in China, with years of experience in providing high-quality solutions. Our competitive pricing and growing popularity in the European and American markets make us the perfect long-term partner for all your On Ff On Round Rocker Switch requirements in China.

Model:GQ116-1-04

Send Inquiry

Product Description

WEIPENG® is a leading China Rectangle Size Rocker Switch manufacturers, suppliers and exporter.

Tongda Wire Electric Rectangle Size Rocker Switch


Tongda Wire Electric Rectangle Size Rocker Switch Introduction
Rectangle Size Rocker Switch is also known as waveform switch, stick switch, rocker switch, IO switch, power switch, because it looks like a boat, so called boat switch, its structure and toggle switch is roughly the same, only the knob is changed into a boat.



Tongda Wire Electric Rectangle Size Rocker Switch Switch Technical Characteristics


Switch Technical Characteristics:
ITEM Technical Parameter Value
1 Electrical Rating 10(1.5)A/16(3)A/10(3)A 250VAC
2 Contact Resistance ≤50mΩ  Initial value
3 Insulation Resistance ≥100MΩ (500VDC)
4
Dielectric
Voltage
Between
non-connected terminals
1500V/0.5mA/60S
Between terminals
and the metal frame
3000V/0.5mA/60S
5 Electrical Life ≥10000 cycles
6 Mechanical Life ≥100000 cycles
7 Operating Temperature 0~125℃
8 Operating Frequency Electrical :15 cycles
Mechanical :60 cycles
9 Vibration Proof Vibration Frequency :10~55HZ;
Amplitude :1.5mm:
Three directions :1H
10 Solder Ability :
More than 80% of immersed part
shall be covered with solder
Soldering Temperature :235±5℃
Immersing Time :2~3S
11 Solder Heat Resistance Dip Soldering :260±5℃ 5±1S
Manual Soldering :300±5℃ 2~3S
12 Safety Approvals UL、CSA、VDE、ENEC、TUV、CE、CQC
13 Test Conditions Ambient Temperature :20±5℃
Relative Humidity :65±5%RH
Air Pressure : 86~106KPa

Tongda Wire Electric Rectangle Size Rocker Switch Feature And Application


These items belong to the category of small household appliances and other electronic products. They comprise of water dispensers, treadmills, printers, televisions, computer speakers, battery-operated cars and motorcycles, ion TVs, coffee makers, plugs, massage machines, electric fans, electric oil heaters, and several others.

Tongda Wire Electric Rectangle Size Rocker Switch Details
