Coffee Machine Micro Switch
  • Coffee Machine Micro SwitchCoffee Machine Micro Switch

Coffee Machine Micro Switch

WEIPENG® has established itself as a top-tier coffee machine micro switch manufacturer and supplier in China, providing quality coffee machine micro switch solutions for many years. We follow the quality of rest assured that the price of conscience, dedicated service.

Model:HK-10-3A-003

Send Inquiry

Product Description


As a professional high quality Coffee Machine Micro Switch manufacturers, you can rest assured to buy Coffee Machine Micro Switch from WEIPENG® and we will offer you the best after-sale service and timely delivery.

Tongda Wire Electric Coffee Machine Micro Switch Introduction


Also known as sensitive switch, quick switch. Pressure actuated quick on/off. Used for door switch in anti-theft system.

Microswitch is small, but it plays an irreplaceable role in our daily life, realizing automatic control and safety protection in the equipment that needs frequent circuit change. At present, it has been widely used in electronic equipment, instruments, mines, power systems, household appliances and equipment, as well as aerospace, aviation, missiles, tanks and other military fields. In addition, they can also be used in computer mice, automobile mice, automobile electronics, communication equipment, military products, as well as test instruments, gas water heaters, gas stoves, small household appliances, microwave ovens, rice cookers, floating ball equipment, medical instruments, building automation, power tools and general electrical and radio equipment, 24 hour timers.

ITEM Main Technical Parameters
1 Electrical Rating :3A 250VAC
2 Electrical lifetime : Min.10000 cycles
3 Contact Resistance :<50mΩ
4 Operating force:70±20gf
5 Free position:7.3±0.2mm
6 Operating position:7.0±0.2mm
7 Ambient temperature:T85°
8 Withstand Voltage :Between terminal and terminal 500V/5S/5mA;
Between terminals and case 1500/5S/5mA
9 Insulation Resistance:>100MΩ  Test Voltage 500VDC
10 Proof Tracking Index PTI :175V

Tongda Wire Electric Coffee Machine Micro Switch Feature and Application


coffee machine micro switch in the need to frequently change the circuit of the equipment for automatic control and safety protection, widely used in electronic equipment, instruments, mines, power systems, household appliances, electrical equipment, and aerospace, aviation, ships, missiles, tanks and other military fields, has been widely used in the above fields, the switch is small, but plays an irreplaceable role.
At present, the mechanical life of microswitches on the domestic market varies from 3W to 1000W times according to the different use requirements, generally 10W, 20W, 50W, 100W, 300W, 500W and 800W times. Beryllium bronze, tin bronze and stainless steel wire are generally used in China as reed. ALPS in foreign countries can do it up to 1000W, their reed is made of rare metal titanium.

Tongda Wire Electric Coffee Machine Micro Switch Details




Hot Tags: Coffee Machine Micro Switch, China, Manufacturers, Suppliers, Wholesale, Factory, Price
